Aten CN9600 1-Local/Remote Share Access Single Port DVI KVM over IP Switch

Hardware Compact and slim design for space utility optimization Provides a FPGA graphics processor for better image quality and enhanced fps (frames per second) throughput for crisp video display response Provides over-IP capability to DVI KVM switches that do not have built-in over-IP functionality* Local console provides USB keyboard and mouse support A mini USB port on the front panel serves as a Laptop USB Console (LUC) port Two 10/100/1000 Mbps NICs for redundant LAN or two IP operation Dual Power Supply for power backup Supports multiplatform server environments: Windows, Mac, Sun, Linux and VT100 based serial devices Virtual Media support** High video resolution – up to 1920 x 1200 @ 60Hz for both local and remote consoles Audio support – microphone and speakers are supported on the local and remote console * Compatible KVM Switch: ATEN DVI Single Link KVM Switches ** Some of the CN9600's features may not be supported, depending on the functionality of the cascaded KVM switch. (For example, some switches do not support virtual media .) Management Complies to the RS-232 DTE/DCE standards for serial control Up to 64 user accounts – up to 32 users can simultaneously share control Console access right management End session feature – administrators can terminate running sessions Event logging and Windows-based Log Server support Event Logging – the CN9600 can record all events that take place on it and write them to a searchable database Supports instant notification of critical system events via email, SNMP trap and Syslog Firmware upgradable via remote access Access the CN9600 via a built-in serial viewer, or via third-party software (such as PuTTY) for Telnet and SSH sessions Out of Band support – access the CN9600 through its serial port using a dial-up connection Port Share Mode allows multiple users to gain access to a server simultaneously Local/Remote Share Mode conveniently grants shared or exclusive console privilege Integration with ATEN CC2000 Management Software Integration with ATEN CCVSR Video Session Recording Software Supports ATEN KVM over IP Console Station ( KA8270 / KA8280 / KA8278 / KA8288 ) DDNS – allows mapping of a dynamic IP address assigned by a DHCP server to a host name Supports export/import of user account and configuration settings Supports permission-controlled browser operation Supports IPv6 Easy-to-Use Interface Browser-based and AP GUIs offer a unified multilanguage interface to minimize user training time and increase productivity Multiplatform client support (Windows, Mac OS X, Linux, Sun) Multibrowser support (IE, Mozilla, Firefox, Safari, Opera, Netscape) Browser-based UI in pure Web technology allows administrators to perform administrative tasks without pre-installed Java software package requirements Full-screen or sizable and scalable Virtual Remote Desktop Magic Panel with configurable function for quick launch Advanced Security Smart Card/CAC Reader support External authentication support: RADIUS, LDAP, LDAPS and MS Active Directory Supports TLS 1.2 data encryption and RSA 2048-bit certificates to secure users logging in from browsers Flexible encryption design allows users to choose any combination of 56-bit DES, 168-bit 3DES, 256-bit AES, 128-bit RC4 or Random for independent keyboard/mouse, video, and virtual media data encryption Supports IP/MAC Filter Supports password protection Private CA Virtual Media Virtual media enables file applications, OS patching, software installation and diagnostic testing Works with USB-enabled servers at OS and BIOS level Supports USB 1.1 and USB 2.0 DVD/CD drives, USB mass storage devices, PC hard drives, folders and ISO images Virtual Remote Desktop Video quality and video tolerance can be adjusted to optimize data transfer speed; monochrome color depth, threshold and noise settings can be adjusted for compression of the data bandwidth in low bandwidth situations Full-screen video display or scalable video display Message Board for communication among remote users On-screen keyboard with multilanguage support Mouse DynaSync™ – automatically synchronizes the local and remote mouse movements Supports Exit Macros BIOS-level access Package Contents 1x CN9600 DVI KVM over IP Switch 1x KVM Cable (DVI-D, USB, Audio; 1.8 m/6 ft) 1x USB Cable (1.8 m/6 ft) 1x Power Adapter 1x Mounting Kit 1x User Instructions Connectors Console Ports 2 x USB Type A Female (White) 1 x DVI-D Female (White) 1 x Mini Stereo Jack Female (Green) 1 x Mini Stereo Jack Female (Pink) KVM Ports 1 x USB Type B Female (White) 1 x DVI-D Female (White) 1 x Mini Stereo Jack Female (Green) 1 x Mini Stereo Jack Female (Pink) LAN Ports 2 x RJ-45 Female Virtual Media 1 x USB Mini-B Female Power 2 x DC Jack Serial 2 x RJ-45 Female Control 1x PS/2 Female Switches Reset 1 x Semi-recessed pushbutton (Black) Emulation Keyboard / Mouse USB LEDs Power 1 (Green) Video Local console - 1920 x 1200 @ 60 Hz Remote - 1920 x 1200 @ 60 Hz Power Consumption DC5V:5.55W:30BTU Environmental Operating Temperature 0 - 50°C (CN9600) 0 - 40°C (Power Adapter) Storage Temperature -20 - 60°C Humidity 0 - 80% RH, Non-condensing Physical Properties Housing Metal Weight 0.84 kg ( 1.85 lb ) Dimensions (L x W x H) 20.00 x 15.49 x 2.85 cm (7.87 x 6.1 x 1.12 in.)
