Aten PE0110SG

Space saving -1U rack mount design IEC or NEMA outlet models Surge Protection Over-current Protection Aluminum material Works with data centers, server rooms and telecom equipment Function PE0110SA PE0110SG Electrical Nominal Input Voltage 100-120 VAC 100-240 VAC Maximum Input Current 15A (Max) (UL de-rated 12A Max) (PSE 10A) 10A (Max) Input Frequency 50-60 Hz 50-60 Hz Input Connection NEMA 5-15P For G Plug：IEC-320 C14 For Ｚ Plug：Chinese 10A Input Power 1800VA(Max);1440VA(UL de-rated) 2400VA(Max) Outlet Type (10) NEMA 5-15R (10) IEC-320 C13 Maximum Output Current (Outlet) 15A (Max) (UL de-rated 12A Max) (PSE 10A) 10A (Max) Maximum Output Current (Bank) 15A (Max) (UL de-rated 12A Max) (PSE 10A) 10A (Max) Maximum Output Current (Total) 15A (Max) (UL de-rated 12A Max) (PSE 10A) 10A (Max) OPD(Overcurrent Protection Device) YES YES Physical Properties Dimensions (L x W x H) 48.20 x 4.44 x 4.50 cm (18.98 x 1.75 x 1.77 in.) 48.20 x 4.44 x 4.50 cm (18.98 x 1.75 x 1.77 in.) Weight 0.66 kg ( 1.45 lb ) 0.66 kg ( 1.45 lb ) Power Cord Length 10ft(14#) 10ft(3×1.5mm2) Environmental Temperature (Operating / Storage) 0 – 40℃ / -20 – 60℃ *When the environmental temperature comes close 40 degrees, it is recommended to lower the load to 60% to comply to the safety regulations. 0 – 40℃ / -20 – 60℃ *When the environmental temperature comes close 40 degrees, it is recommended to lower the load to 60% to comply to the safety regulations. Elevation (Operating / Storage) 3000m 3000m Compliance EMC Verification FCC Class A - Safety Verification By Request LVD Note For some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format. Package Contents 1x Basic PDU 1x Power cord 1x User Instructions
