Aten VC060

Superior video quality – HDTV resolutions of 480i, 480p, 720i, 720p, 1080i, 1080p (1920 x 1080); VGA, SVGA, XGA, SXGA, UXGA and WUXGA (1920 x 1200) EDID Wizard – allows a user an easy way to manage EDID settings EDID mode selection – Default, Learning , Programming Automatically manages EDID communication between connected devices Signaling rates up to 2.25 Gbits in support of 1080p display LED indication of video source devices Supports wide screen Supports hot-plugging Non-Powered * * If the video source is not receiving enough power an external power cord should be connected. Video Input Interfaces 1 x DVI-I Female (White) Impedance 100 Ώ Video Output Interfaces 1 x DVI-I Female (White) Impedance 100 Ώ EDID Settings EDID Mode: Default / Learn / Customized (EDID Wizard support) Connectors Power 1 x DC Jack Power Consumption DC5V:0.13W:1BTU Environmental Operating Temperature 0 - 50 ºC Storage Temperature -20 - 60 ºC Humidity 0 - 80% RH, Non-Condensing Physical Properties Housing Metal Weight 0.15 kg ( 0.33 lb ) Dimensions (L x W x H) 7.90 x 7.86 x 2.45 cm (3.11 x 3.09 x 0.96 in.)
